Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
2-1462051-3 | ||
|---|---|---|
Digi-Key Part Number | PB2103TR-ND - Tape & Reel (TR) PB2103CT-ND - Cut Tape (CT) PB2103DKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | 2-1462051-3 | |
Description | RELAY RF SPDT 2A 5V | |
Manufacturer Standard Lead Time | 65 Weeks | |
| Customer Reference | ||
| Datasheet | Datasheet | |
Product Attributes
Type | Description | Select |
|---|---|---|
Category | ||
Mfr | TE Connectivity Potter & Brumfield Relays | |
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Coil Type | Non Latching | |
Coil Current | 28 mA | |
Coil Voltage | 5VDC | |
Contact Form | SPDT (1 Form C) | |
Contact Rating (Current) | 2 A | |
Switching Voltage | 250VAC, 220VDC - Max | |
Must Operate Voltage | 3.75 VDC | |
Must Release Voltage | 0.5 VDC | |
Operate Time | 5 ms | |
Release Time | 5 ms | |
Features | - | |
Mounting Type | Surface Mount | |
Termination Style | Gull Wing | |
Operating Temperature | -55°C ~ 85°C | |
Contact Material | Silver (Ag), Gold (Au) | |
Coil Power | 140mW | |
Coil Resistance | 178 Ohms | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | |
| Video File | How to Choose a Relay - Another Teaching Moment Relay Basics - Another Teaching Moment | DigiKey Electronics TE Connectivity Relay Products | Digi-Key Daily |
| Environmental Information | 2-1462051-3 Statement of Compliance |
| Featured Product | Relay Products |
| PCN Design/Specification | |
| PCN Packaging | (y)-1462051-y Packaging Label 21/May/2018 |
| HTML Datasheet | |
| EDA Models | 2-1462051-3 by SnapEDA |
| 3D Drawings | 2-1462051-3.pdf |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | Vendor Undefined |
| ECCN | EAR99 |
| HTSUS | 8536.41.0020 |
1.455 In Stock
All prices are in EUR
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | 19,03000 € | 19,03 € |
| 10 | 18,08000 € | 180,80 € |
| 25 | 17,12880 € | 428,22 € |
| 50 | 16,17740 € | 808,87 € |
| 100 | 15,22570 € | 1.522,57 € |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 400 | 14,27408 € | 5.709,63 € |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | PB2103CT PB2103TR PB2103DKR 2-1462051-3-ND |
| Standard Package | 400 |
