CP1A-12V, CP1-12V
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

CP1-12V

Digi-Key Part Number
255-1939-ND
Manufacturer
Panasonic Electric Works
Manufacturer Product Number
CP1-12V
Description
RELAY AUTOMOTIVE SPDT 20A 12V
Manufacturer Standard Lead Time
24 Weeks
Customer Reference
Datasheet Datasheet
Product Attributes
Type
Description
Select
Category
Mfr
Panasonic Electric Works
Series
CP
Package
Tube
Product Status
Active
Coil Type
Non Latching
Coil Current
53.3 mA
Coil Voltage
12VDC
Contact Form
SPDT (1 Form C)
Contact Rating (Current)
20 A
Switching Voltage
14VDC - Nom
Must Operate Voltage
7.2 VDC
Must Release Voltage
1 VDC
Operate Time
10 ms
Release Time
10 ms
Features
Sealed - Fully
Mounting Type
Through Hole
Termination Style
PC Pin
Operating Temperature
-40°C ~ 85°C
Contact Material
Silver Alloy, Cadmium Free
Coil Power
640mW
Coil Resistance
225 Ohms
Documents & Media
Resource TypeLink
DatasheetsCP Series
Other Related Documents
Video File
How to Choose a Relay - Another Teaching Moment
Relay Basics - Another Teaching Moment | DigiKey Electronics
EDA ModelsCP1-12V by Ultra Librarian
Product Drawings
Environmental & Export Classifications
AttributeDescription
RoHS StatusRoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
ECCNEAR99
HTSUS8536.41.0050
6.023 In Stock
All prices are in EUR
Tube
QtyUnit PriceExt Price
12,63000 €2,63 €
102,47000 €24,70 €
252,19520 €54,88 €
502,08560 €104,28 €
1001,97570 €197,57 €
2501,75624 €439,06 €
5001,64648 €823,24 €
1.0001,53671 €1.536,71 €
5.0001,48182 €7.409,10 €
You May Also Be Interested InSee All 25
Additional Resources
AttributeDescription
Other Names
CP112V
CP1-12V-ND
255-1939
Standard Package40
