Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
NOSB226M006R0600 | ||
|---|---|---|
Digi-Key Part Number | 478-NOSB226M006R0600TR-ND - Tape & Reel (TR) 478-NOSB226M006R0600CT-ND - Cut Tape (CT) 478-NOSB226M006R0600DKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | NOSB226M006R0600 | |
Description | CAP NIOB OXID 22UF 20% 6.3V 1210 | |
Detailed Description | 22 µF Niobium Oxide Capacitor 6.3 V 1411 (3528 Metric), 1210 600 mOhms | |
Customer Reference | ||
Datasheet | Datasheet | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | KYOCERA AVX | |
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Capacitance | 22 µF | |
Tolerance | ±20% | |
Voltage - Rated | 6.3 V | |
ESR (Equivalent Series Resistance) | 600 mOhms | |
Current - Leakage | 2.6 µA | |
Dissipation Factor | 6% | |
Mounting Type | Surface Mount | |
Package / Case | 1411 (3528 Metric), 1210 | |
Manufacturer Size Code | B | |
Height - Seated (Max) | 0.083" (2.10mm) | |
Features | Low ESR | |
Operating Temperature | -55°C ~ 125°C | |
Supplier Device Package | 1210 (3528 Metric) | |
Size / Dimension | 0.138" L x 0.110" W (3.50mm x 2.80mm) |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | NOS OxiCap Low ESR Series |
| Product Training Modules | |
| Design Resources | SpiTAN Design Tool |
| HTML Datasheet | NOS OxiCap Low ESR Series |
| Product Drawings | NO(J,S) Series Sides |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8532.29.0040 |
In-Stock: 2.695
Quantity
All prices are in EUR
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | 0,93000 € | 0,93 € |
| 10 | 0,69700 € | 6,97 € |
| 50 | 0,63560 € | 31,78 € |
| 100 | 0,52080 € | 52,08 € |
| 500 | 0,41566 € | 207,83 € |
| 1.000 | 0,36676 € | 366,76 € |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 2.000 | 0,34231 € | 684,62 € |
| 4.000 | 0,33008 € | 1.320,32 € |
| 10.000 | 0,31786 € | 3.178,60 € |
| 14.000 | 0,31174 € | 4.364,36 € |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 478-3244-2-ND 478-3244-1 478-3244-2 478-NOSB226M006R0600CT 478-NOSB226M006R0600TR 478-3244-6 478-3244-6-ND 478-3244-1-ND 478-NOSB226M006R0600DKR |
| Standard Package | 2.000 |
