100SP1T4B1M1QEH
Digi-Key Part Number	EG2367-ND
Manufacturer	E-Switch
Manufacturer Product Number	100SP1T4B1M1QEH
Description	SWITCH TOGGLE SPDT 5A 120V
Manufacturer Standard Lead Time	13 Weeks
Detailed Description	Toggle Switch SPDT Panel Mount
Customer Reference
Datasheet	Datasheet

Type	Description	Select
Category	Switches Toggle Switches
Mfr	E-Switch
Series	100
Package	Bulk
Product Status	Active
Mounting Type	Panel Mount
Circuit	SPDT
Switch Function	On-On
Current Rating (Amps)	5A (AC/DC)
Voltage Rating - AC	120 V
Voltage Rating - DC	28 V
Actuator Type	Standard Round
Actuator Length	16.26mm
Illumination	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage (Nominal)	-
Termination Style	Solder Lug
Panel Cutout Dimensions	Circular - 6.35mm Dia
Bushing Thread	1/4-40
Ingress Protection	-
Features	Epoxy Sealed Terminals
Operating Temperature	-30°C ~ 85°C
Actuator Material	Brass, Chrome Plated
Electrical Life	40,000 Cycles
Base Product Number	100SP1

Resource Type	Link
Datasheets	100 Series Datasheet
Product Training Modules	Power Switch Overview Switch Basics
Video File	Additional Requirements for Selecting a Switch How Does the Switch Attach to your Product What Electrical Ratings do You Need?
Environmental Information	E-Switch RoHS 3 Cert
CAD Models	100SPxT4B1M1xE.stp
HTML Datasheet	100SP1T4B1M1QEH Drawing
Product Drawings	100SP1T4B1M1QEH Drawing B1 Bushing M1 Termination T4 Extended Actuator

Attribute	Description
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.50.9065

Attribute	Description
Other Names	T111096 100SP1T4B1M1QE EG2367
Standard Package	66
